Unit dimensions

• 2.4” x 2.4” x 2.2” (6.1 x 6.1 x 5.1 cm)

Hardwire power

• 12V/24V

Operating current

• 300 mA at 12VDC; 200 mA at 24VDC

Power consumption

• 4.5 W

Connection to chartplotter

• IP

Versatile mounting options

• yes (ball-up or ball-down)

Rugged housing

• yes

Setup

• plug-and-play

Video resolution

• 1920 x 1080 pixels*

Video output

• H.264 over GMN and BlueNet™

Images

• Standard and reverse

Selectable views

• FishEye, standard, BirdsEye (OEM calilbrated)

Augmented reality features

• Distance markers (OEM calibrated) and guidance lines (user setup)

Viewing angle (H/V)

• 160°H/90°V

Scanning system

• progressive scan

Day/night operation

• RGB mode full-time

Unit dimensions

• 3.2” x 3.2” x 3.3” (8.1 x 8.1 x 8.38 cm), body; 3.2" x 3.2" x 0.95" (8.1 x 8.1 x 2.4 cm)

Versatile mounting options

• thru-hull installation

Rugged housing

• yes (high impact)

Install below rub rail

• yes

Max Range

• 96 nm

Transition Power

• 120 W

Dual Range Support

• yes

Radar Overlay Support

• yes

Dual Radar

• yes

AutoBird

• yes

Dynamic Auto Gain

• Dynamic

MARPA Target Track

• yes (requires heading sensor, sold separately)

Scan

• yes

Transition Power

• 250 W power output, the approximate equivalent to a 15 kW magnetron

Echo Trail

• yes

Max Range

• 72 nm

Transition Power

• 50 W

NMEA 2000® compatible

• yes

Sizes

• 6.5"

RMS power

• 6.5" speaker: 75 W

Nominal impedence

• 4 ohms

LED load current @14.4 VDC

• 6.5" speaker: 0.13 A per color, per speaker

LED load current @14.4 VDC when using Garmin Spectra™¹

• 6.5" speaker: 0.28 A maximum per speaker

LED connection

• 5.9" (150 mm) water-resistant 6-way connector (6-pin, CRGBW and ground)

Sizes

• 7.7"

RMS power

• 7.7" speaker: 100 W

LED load current @14.4 VDC

• 7.7" speaker: 0.14 A per color, per speaker

LED load current @14.4 VDC when using Garmin Spectra™¹

• 7.7" speaker: 0.31 A maximum per speaker

Sizes

• 8.8"

RMS power

• 8.8" speaker: 130 W

LED load current @14.4 VDC

• 8.8" speaker: 0.18 A per color, per speaker

LED load current @14.4 VDC when using Garmin Spectra™¹

• 8.8" speaker: 0.38 A maximum per speaker

Input current (max)

• LC102: 2 A

Output current (max)

• 2 A (per output connector)

NMEA 2000® LEN

• 2 (? 70 mA)

Over current protection

• yes

LED connection types

• RGB, RGBW, CRGBW, single channel

Lighting modes

• Color pick, audio sync (color blend/audio spectrum), effects

Premium control and setup via

• MFD or ActiveCaptain® app

Control via

• Fusion Apollo™ Stereo

Over voltage protection

• yes

Tank pressure transmission range

• Up to 10 m (33 ft)

Dive messaging

• Up to 30 m (98 ft); requires compatible Descent Mk3i dive computer

Input current (max)

• LC302: 6 A

Cable reel length

• 328 ft (100 m)

Temperature rating

• 14° to 221° F (-10° to 105° C)

Fire retardant rating

• VW-1

Voltage rating

• 300 V max

Oil resistance

• yes

Cable construction

• 6 core, multistrand tinned copper with white PVC outer jacket

Maximum cable connection length

• 16 AWG (1.3 mm2): 28 ft (9 m)

Temperature rating

• Dry: 221° F (105° C)

Voltage rating

• 600 V max

Cable construction

• Multistrand tinned copper with white PVC outer jacket

Maximum cable connection length

• 12 AWG (3.3 mm2): 70 ft (21 m)

Temperature rating

• Wet: 194° F (90° C)

Sizes

• 10"

RMS power

• 10" subwoofer: 300 W

LED load current @14.4 VDC

• 10" subwoofer: 0.19 A per color

LED load current @14.4 VDC when using Garmin Spectra™¹

• 10" subwoofer: 0.40 A maximum

Sizes

• 12"

RMS power

• 12" subwoofer: 700 W

AutoGain Technology (minimises clutter, maximises targets)

• yes

Water temperature sensor included

• yes

minimum depth

• 3' (0.91 m)

Dimensions (WxHxD) (unit only)

• 9.1' x 4.2' x 1.5' (230 x 106 x 38 mm)

Weight (unit only)

• 14.1 oz (400 g)

Ambient temperature

• -20° C to +55° C

Enclosure water rating

• IP65

High side

• 13 ch 10A, 7 ch 5A

Ground contact switch input

• 15

Bilge pump monitor

• 2

Volt

• 3 @ 0-16 V +/-1%

Resistance

• 2 @ 0-1500 ohm +/- 5%

Maximum current

• 50A

Power off current consumption

• 60mA

Supply voltage (12V)

• 9-16VDC

NMEA 2000®

• Micro 5-pin M12 male

Power terminal

• M6 bolt

SBAS

• yes

Geocaching-friendly

• Yes (paperless)

Dimensions without sun cover (HxWxD)

• 4.1" x 4.5" x 2.0" (10.5 x 14.0 x 5.1 cm)

Dimensions with sun cover (HxWxD)

• 4.1" x 4.5" x 2.0" (10.5 x 14.0 x 5.1 cm)

Weight without sun cover

• 11.6 oz. (328 g)

Weight with sun cover

• 13.2 oz. (375 g)

Brightness

• 1200 cd/m2 (NIT)

NMEA 2000® input voltage

• 9 to 16 Vdc

NMEA 2000 LEN @ 9 Vdc

• 13 (650 mA)

Dimensions (WxHxD)

• Flush mount: 1.6” x 6.2” x 0.28” (40.1 x 157.0 x 7.0 mm) Surface mount: 1.6” x 6.2” x 0.65” (41.1 x 158.0 x 16.4 mm)

Material

• Fully-gasketed, high-impact plastic

Powered input

• Powered supplied from the NMEA 2000® network

Dimensions (WxHxD)

• Flush mount: 5.5” x 2.3” x 0.28” (139.7 x 57.4 x 7.0 mm) Surface mount: 5.5” x 2.3” x 0.65” (140.7 x 58.4 x 16.4 mm)

Lift-assist

• dual gas springs

Manual reverse control

• yes

Smart Anchor Lock features

• yes

Anchor lock jog

• yes

Water Temperature Log

• yes

Typical current draw

• 0.55 A

Max current draw

• 1.5 A

Power consumption

• 6.6

Split-screen zoom

• yes

Depth range shading

• yes

Physical dimensions (Height)

• 3.23" (82 mm)

Physical dimensions (Width)

• 7.56" (192 mm)

Physical dimensions (Depth)

• 4.7" (119.4 mm)

Control Surface Dust/Water Rating (when properly installed)

• IPX6 and IPX7

Rear Dust/Water Rating (when properly installed)

• IPX3

Current draw (max)

• 25 A at 14.4 V; 15A at 28.8 V

NMEA 2000® LEN

• 2 (65 mA)

BLUETOOTH® wireless range

• up to 30 ft

ANT® wireless range

• Up to 10 ft

Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD)

• 40 W x 4

Optically bonded display

• yes

Built-in Digital Signal Processing (DSP)

• yes (with custom DSP profile setup using Fusion-Link™ app)

Stereo networking

• yes (wired or wireless)

BLUETOOTH® wireless technology

• yes

ANT® wireless technology

• yes

Supported sources

• AM, FM, BLUETOOTH®, Apple AirPlay® 2, HDMI ARC, USB audio, iPhone, iPod, AUX x2

Supported audio formats (USB)

• MP3, AAC, M4A, FLAC, WAV

Auxiliary inputs (RCA)

• 2

HDMI ARC Ports

• 1

Ethernet ports

• 1

USB 2.0 ports

• 1 (USB-C)

AM/FM ports (Motorola antenna connector)

• 1

Speaker connections

• 4 (2 zone amplified)

RCA pre-out (left, right and subwoofer - requires external amplification)

• 4 zones

Line out (requires external amplification)

• 4 (L + R per zone)

Subwoofer out (requires external amplification)

• 4 (1 mono output per zone)

Supports voice commands

• yes

Shaft length (from mount to top of drive motor)

• 16.6" (max); 11.4" (min)

Power steer foot pedals (kayak) compatible

• yes (included)

MAXIMIUM POWER USAGE AT 10 VDC

• 26.5W

SONAR RECORDING

• yes

Sensitivity (1 watt @ 1 metre)

• Touchscreen

BLUECHART(COASTAL)

• yes

MAXIMIUM POWER USAGE AT 10 VDC

• 22.0W

Polarized lens viewability

• yes

GRID 20 compatible

• yes

Supports built-in xCHIRP

• yes (with compatible black box sonar)

Supports built-in RapidReturn

• yes (with compatible black box sonar)

ANT® (Connectivity)

• yes

Wi-Fi frequency bands

• 2.4 GHz & 5 GHz

NMEA0183

• yes

Voltage rating

• 12.0 Vdc

Physical dimensions (Height)

• 1.86" (47 mm)

Physical dimensions (Width)

• Monoblock/4 Channel: 10.43" (265 mm) 6 Channel: 11.81" (300 mm)

Physical dimensions (Depth)

• Monoblock/4 Channel: 4.90" (125 mm) 6 Channel: 5.90" (150 mm)

Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD)

• Monoblock: 200 W x 1 4-Channel: 50 W x 4/150 W x 2 (Bridged) 6-Channel: Channels 1-4: 50 W x 4/150 W x 2 (Bridged); Channels 5-6: 100 W x 2/300 x 1 (Bridged)

Rated continuous (RMS) power (14.4 V input @ 2 Ohm < 1% THD)

• Monoblock: 350 W x 1 4 Channel: 75 W x 4 6-Channel: Channels 1-4: 75 W x 4; Channels 5-6: 150 W x 2

Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs

• >70 dB

Frequency response (+0, -1dB)

• Monoblock: 10 Hz-500 Hz 4/6-Channel: 20 Hz-20 kHz

Input sensitivity @ RCA inputs

• Switchable from 200 mV-2 V RMS (Low) to 800 mV-8 V RMS (High)

Recommended fuse type(s)

• AFS, AGU or MaxiFuse™

Min. copper power/Ground wire gauge

• 4 AWG wire

Filter mode(s): Channels 1 & 2

• Monoblock: Low-pass 4/6-Channel: Off, Low-pass or High-pass

Filter Slope(s): Channels 1 & 2

• 12 dB/octave

Filter frequency range: Channels 1 & 2

• 20 Hz-500 Hz

Filter mode(s): Channels 3 & 4

• 4/6-Channel: Off, Low-pass or High-pass

Shaft length (from shaft cap to shaft end)

• 42" or 49"

Adjustable shaft depth

• yes

Water rating (components above water)

• IPX7

Deck stabilizer rod

• yes (included)

Dogbone stabilizer

• compatible, required with 2 or more transducers (not included)

LiveScope™ adjustable perspective bottom mount

• Included: Forward, Down and Perspective at 0° , 7.5°, 15°, 22.5°

Supported LiveScope transducers

• LVS32, LVS34, LVS62 (max of one with internal cable routing)

OneVü scanning transducer support

• yes

Internal cable routing

• yes

Quick-release cable kit

• yes

Compatible chartplotters

• Wireless

Compatible Force trolling motors

• Wireless

Control accessories

• Wireless

Maximum connections

• 5 gesture remotes 1 foot control 1 heading sensor 1 trolling motor 1 chartplotter network

Power supply

• 2 AA batteries (not included)

Battery life (typical use)

• 1 full season

Programmable buttons

• yes (2)

Status indication

• LED light

Quick-release mount

• yes

Remote Dimensions

• 1.25" diameter x 0.5“ thickness

Remote Wireless communication

• yes

Remote Power supply

• CR2032 battery (included)

Remote Battery life (typical use)

• 1 full season

Remote Water rating

• IPX7

Remote Programmable buttons

• yes (3)

Remote Status indication

• LED light

Remote Quick-release mounting options

• 2 rod, hat, handheld with lanyard

Remote Floats

• yes (with handheld only)

Remote Steering

• yes (swing and twist)

Heading Sensor Dimensions

• 3.5" x 2.0" x 1.0"

Heading Sensor Wireless communication

• yes

Heading Sensor Voltage

• 10 V-45 V

Heading Sensor Power input

• Wired, 2 m (6.5 ft) cable

Heading Sensor Power usage

• 0.1 W typical; 1 W max

Heading Sensor Fuse

• 1 A

Heading Sensor Water rating

• IPX7

Heading Sensor Status indication

• LED light

Unit size

• Head Unit: 75 x 160 x 29 mm (3.0" x 6.3" x 1.2") Fist Mic: 100 x 60 x 31 mm (3.9" x 2.4" x 1.2")

Adaptive noise cancellation

• yes

Audio record and playback

• yes

Auto squelch

• yes

Dual/Tri watch

• yes

Presets watch

• yes

NOAA weather alert

• yes

NOAA weather watch

• yes

Intercom support

• yes

AIS target display

• yes

AIS collision and MOB alarms

• yes

Max speaker output power

• Fist Mic: 5 W RMS, < 1% THD

External speaker

• yes

Max external speaker output power

• 15 W RMS, < 1% THD, 4

Garmin Marine Network

• GMN 1.0/2.0

Unit size

• Head Unit: 75 x 160 x 104 mm (3.0" x 6.3" x 4.1") Fist Mic: 100 x 60 x 31 mm (3.9" x 2.4" x 1.2")

Inland waterways (ATIS)

• yes

Dual/Tri watch

• yes

Loud hailer

• yes

Loudhailer listen back

• yes

Integrated AIS transponder

• yes

Region

• All U.S., Canadian and International marine channels; NOAA weather channels

VHF frequency range Tx

• 156.025–162.025 MHz

VHF frequency range Rx

• 156.025–163.275 MHz

VHF transmit power (max)

• 25 W, 1 W (high, low)

Adjacent channel power

• more than 70 dB

Spurious emissions

• Less than –80 dBc (at 25 W)

Sensitivity (12 dB SINAD)

• -118 dBm (-11 dBu/0.28 uV)

Adjacent channel selectivity

• 80 dB

Spurious response

• more than 75 dB

VHF intermodulation

• more than 75 dB

Max antenna gain

• 6 dBi

Class

• Class D

Sensitivity (1 BER)

• -117 dBm (-10 dBu/0.32 uV)

Intermodulation

• more than 75 dB

Remote station support

• RM 100 (x5)

Target separation @ 30

• 3.8"

Power connection

• yes (2-wire)

Water detection transmit control

• yes
